Hydraulic Support Jack | ||||||||||
Work Press | Customized | |||||||||
Delivery Time | Discuss delivery time based on order quantity | |||||||||
Cylinder Model | Rated pressure (MPa) | Maximum Cylinder Diameter (mm) | aximum thrust(T) | Stroke (mm) | M | |||||
4TG-E150*830ZJ/A | 16 | 156 | 30 | 830 | M22*1.5 internal thread | |||||
4TG-E140*800ZJ/A | 16 | 141 | 25.5 | 800 | M27*2 internal thread | |||||
4TG-E140*730ZJ/A | 16 | 141 | 25.5 | 730 | M27*2 internal thread | |||||
4TG-E135*800ZJ/A | 16 | 141 | 25.5 | 800 | M27*2 internal thread | |||||
4TG-E135*730ZJ/A | 16 | 141 | 25.5 | 730 | M27*2 internal thread | |||||
4TG-E130*750ZJ/A | 16 | 135 | 23.4 | 750 | M27*2 internal thread | |||||
Sanitation Equipment Cylinder | ||||||||||||
Work Press | Customized | |||||||||||
Rod Diameter | Customized | |||||||||||
Journey | Customized | |||||||||||
Cylinder height | Customized | |||||||||||
Applicable Media | Hydraulic Oil | |||||||||||
Work Pressure | 20Mpa Or Customized | |||||||||||
Application | Various Hydraulic Equipment | |||||||||||
Excavator Bucket Cylinder | ||||||||||||
Work Press | Customized | |||||||||||
Delivery Time | iscuss delivery time based on order quantity | |||||||||||
model | Installation Distance (mm) | Journey(mm) | Cylinder Diameter (mm) | Rod Diameter (mm) | Work Pressure (MPa) | Oil Port Size (mm) | ||||||
HSG-110/70*350-00 | 680 | 350 | 110 | 70 | 25 | G1/2” | ||||||
HSG-CA-CA-125/70X200-00 | 665 | 200 | 125 | 70 | 20 | M16*1.5 | ||||||
SG-G220X800-00 | 900 | 800 | 220 | 160 | 20 | G1/2” | ||||||
HSG-CA-CA-300/220X2180-00 | 3100 | 300 | 220 | 2180 | 20 | G1/2” | ||||||
HSG-340/250*1200-00 | 990 | 340 | 250 | 1200 | 25 | G1/2” | ||||||
Mining Machinery Cylinder | ||||||||||||||||
Work Press | Customized | |||||||||||||||
After-sales | One-year warranty | |||||||||||||||
Delivery Time | Discuss delivery time based on order quantity | |||||||||||||||
Material | 27 Silicon Manganese | |||||||||||||||
Piston rod material | 42 CrMo Forging | |||||||||||||||
color | Customizable | |||||||||||||||
Sanitation Equipment Cylinder/Agricultural machinery cylinder | ||||||||||||||||
Work Press | Customized | |||||||||||||||
model | Product Name | Cylinder Diameter | Rod Diameter | Journey | Installation Distance | Mounting Holes | Work Pressure | Operating Temperature | ||||||||
Split Station | Displacement Cylinder | 100 | 70 | 3200 | 20 | 50 | 18 1 | homoeothermy | ||||||||
Hook Cylinder | 80 | 45 | 125 | 430 | 35 | 16 | homoeothermy | |||||||||
Main Push Head Cylinder | 160 | 110 | 2700 | 1000 | 60 | 16 | homoeothermy | |||||||||
Lock Box Cylinder | 63 | 32 | 140 | 420 | 25 | 16 | homoeothermy | |||||||||
Push-Pull Box Cylinder | 63 | 32 | 240 | 108 | 25 | 16 | homoeothermy | |||||||||
Door Lifting Cylinder | 63 | 35 | 1010 | 92 | 25 | 16 | homoeothermy | |||||||||
Flip Cylinder | 100 | 70 | 560 | 890 | 50 | 16 | homoeothermy | |||||||||
Push Head Cylinder | 125 | 90 | 1625 | 2120 | 50 | 16 | homoeothermy | |||||||||
Vertical Stand | Safety Hook Cylinder | 50 | 28 | 125 | 365 | 25 | 18 | homoeothermy | ||||||||
Pressing Cylinder | 250 | 180 | 1850 | 1000 | 180球头 | 25 | homoeothermy | |||||||||
Hanging Box Cylinder | 50 | 28 | 145 | 405 | 25 | 18 | homoeothermy | |||||||||
Push Plate Cylinder | 145 | 63 | 3900 | 1800 | 50 | 21 | homoeothermy | |||||||||
Pressing Cylinder | 180 | 125 | 1450 | 700 | 70 | 25 | homoeothermy | |||||||||
Gate Cylinder | 63 | 45 | 1300 | 500 | 25 | 18 | homoeothermy | |||||||||
Push Head Cylinder | 110 | 80 | 800 | 1100 | 45 | 16 | homoeothermy | |||||||||
Tailgate Cylinder | 63 | 45 | 520 | 880 | 25 | 16 | homoeothermy | |||||||||
Flip Cylinder | 100 | 70 | 530 | 930 | 40 | 16 | homoeothermy | |||||||||
Rear Door Locking Cylinder | 50 | 28 | 100 | 355 | 17 | 16 | homoeothermy | |||||||||
Compression garbage truck cylinder | ||||||||||||||||
Hook-Arm Vehicle | ||||||||||||||||
